If you’re building a daily-driven Rocklander (trail-capable, road-friendly), rocker protection with a usable step is a smart first mod. In this guide, I’ll show how I installed the Motobilt rocker armor + step on my Jeep Gladiator (JT), including alignment tricks, a cleaner way to drill for nutserts, and how the step tucks under split fenders for a factory-like fit.
Project Overview
Vehicle: Jeep Gladiator JT
Armor: Rocker armor + bolt-on step (Motobilt)
Difficulty: Intermediate (drilling into body, setting nutserts)
Time: 2–4 hours per side (your first side is slower)
Why do this: Protect the body, gain a sturdy step, and prep for big tires and real trail use.
Tools & Supplies
- Masking tape (paint protection + layout)
- Cardboard shims (to fine-tune the gap and support during mock-up)
- floor Jack
- Sharpie / scribe
- Drill + bits:
- 1/4" (self-centering trick)
- 25/64" (typical for these nutserts—verify your kit)
- Countersunk armor as a “guide” (explained below)
- Rivnut/nutsert setting tool
- Ratchets/sockets (body bolts and hardware)
- Anti-seize compound (on stainless hardware—trust me)
- Safety glasses, hearing protection, gloves, shop rags
Safety First: You are drilling the body. Measure twice, drill once, wear PPE, and follow torque specs from your hardware kit.
Before You Start: Fitment Notes
-
Read the body lines by feel. Use tape to protect paint and give yourself a visual edge. I check the door reveal by touch and shim until the gap feels even.
-
Split fenders? With the right combo, the step will tuck under the front fender split. On my JT I didn’t need to trim after the split. Your setup may vary.
Step-by-Step Installation
1) Mock-Up & Protect Paint
-
Tape along the rocker to protect the body where the armor will sit. Tape doesn’t have to look pretty; it just needs to shield paint while you test-fit.
-
Shim the armor in place with small cardboard shims. Align by the door reveal and body line—aim for an even gap end-to-end.
-
Once the position feels right, spot-hold the armor with a small strip of tape so it doesn’t wander.
Pro Tip: As an alignment check, gently run your fingers along the reveal. If it feels consistent, it usually is.
2) Mark Hole Centers
-
With the armor held in position, mark the first few holes (front and mid) using a Sharpie.
-
Double-check alignment—front, center, rear—before any drilling.
3) Drill Clean Pilot Holes (The Self-Centering Hack)
This trick sped my second side way up and produced cleaner holes:
-
The armor’s countersinks act like a funnel. Use a 1/4" bit inside the countersink to self-center as you start each hole.
-
After starting each hole at 1/4", step up to 25/64" for the nutserts (confirm your kit’s spec).
Why it works: The 1/4" bit nests in the countersink, keeping the hole centered and reducing “chewed” edges.
Avoid “chewed” holes: Keep drill speed controlled and pressure steady. Let the bit cut—don’t force it.
4) Install Nutserts (Rivnuts)
-
Deburr each hole lightly.
-
Thread a nutsert onto the tool so the top of the tool’s threads are flush with the top of the nutsert—this gives you a full, confident crimp without stripping.
-
Seat the nutsert fully into the hole, then squeeze the tool to crimp.
-
Verify it’s tight and fully set—no gap at the throat.
Anti-Seize Tip: Save anti-seize for final assembly. Apply a thin film to stainless hardware to prevent galling.
5) Mount the Rocker Armor
-
With nutserts set, hold the armor in position and start all hardware by hand (with a touch of anti-seize).
-
Snug from the center out to pull the panel flush and keep stress even.
Tiny Alignment Fix: If one hole is just barely off, insert a slim screwdriver behind the panel as a backer and use a slightly larger bit to kiss the taper and open the edge just a hair. Don’t overdo it.
6) Prep & Install the Step
-
Remove the body bolts where the step mounts (these can be stubborn—expect some effort).
-
Hang the U-nut clips in the step where required.
-
Slide the step in from the side—on my split fender setup it tucks under the front fender split perfectly.
-
Start two top bolts to hold position, then reinstall body bolts and work from top to bottom, tightening gradually.
Lessons Learned (So You Don’t Repeat Them)
-
Heat makes everything harder. If you can, avoid peak heat—sweat + anti-seize = mess.
-
Anti-seize carefully. A little goes a long way. If you drop a bolt in it, that rag you use to wipe it off is now a “trash rag.”
-
Start small, then step up. The 1/4" self-centering pass inside the countersink kept holes true and cleanup minimal.
-
Center-out tightening helps prevent a mid-panel “sag” and keeps the armor flush.
My Gladiator Setup (Context)
-
Rocker armor + step, split fender bracket with LED, front high-clearance inner fenders, rear inner fenders, chase rack, inner door molle, spare tire carrier, bed molle.
-
Milestar Patagonia MT02 38s with custom flake + candy Method 323 wheels.
-
Goal: Hybrid overland/trail rig that commutes daily and can still run real trails without compromising long road trips.
Troubleshooting & FAQs
Q: My hole is slightly low or high—now what?
A: Don’t wallow the whole thing. Use the taper “kiss” method: controlled touch with a slightly larger bit, backed by a slim screwdriver to protect the body, just to open the edge enough for alignment.
Q: What size bit for the nutserts?
A: Many kits call for 25/64", but always confirm your kit’s spec. Start with 1/4" in the countersink for a self-centered pilot.
Q: Do I need anti-seize?
A: For stainless into nutserts—yes. It prevents galling and makes service easier later.
Q: Do split fenders require trimming for the step?
A: On my setup, the step tucked under the fender split with no trimming. Your combination of fenders/armor may differ—mock it up before drilling.
Wrap-Up
This install adds real protection and everyday usability without sacrificing your rig’s lines. With careful alignment, the self-centering drill trick, and a light touch on anti-seize, your second side will feel like a professional production run.
